Specifications:
New mini 030 motor,the motor shell is sprayed with high-grade lacquer.
Very beautiful. the motor uses carbon brushes (long life). after testing the motor can be used at
DC 1.5V-3.7V (cannot exceed the voltage range). the speed is particularly high .
The application is very extensive: climbing car, model car, model , remote control car,
electric toy, rail car, toy excavator, technology production, model design, electronic competition,
product development. For DIY production.
Note: This mini 030 carbon brush motor is large current motor, so it needs the special battery as power supply, and it can not use the normal dry batteries. Please make sure the battery you used can drive it.
Package List:
Motor x 1PCS
1.Model: Mini 030 Motor
2.Motor size: 18.6mm*15.4mm*11.8mm
3.Output shaft diameter: 1.5mm
4.Output shaft length: 6.5mm (not include step height)
5.Voltage range: DC 1.5V-3.7V (Different models have different voltage ranges)
6.Test data:
Model A: Blue color motor
1.Rated voltage: DC 2.4V
2.No-load current: 0.7A
3.No-load speed: 36000RPM
4.Suitable voltage: DC 1.5V-3.0V
5.Speed range: 22500RPM-45000RPM
Model B: Red version motor
1.Rated voltage: DC 3.2V
2.No-load current: 0.7A
3.No-load speed: 43000RPM
4.Suitable voltage: DC 1.5V-3.7V
5.Speed range: 21000RPM-49500RPM
Model C: Yellow version motor
1.Rated voltage: DC 3.7V
2.No-load current: 0.6A
3.No-load speed: 44000RPM
4.Suitable voltage: DC 1.5V-5.0V
5.Speed range: 17800RPM-59000RPM
==============================

• Date First Available ‏ : ‎ January 13, 2025
• Manufacturer ‏ : ‎ ANETEE
